Comica CVM-AX3 - Page 5

Components and Instruction
Audio Mixer
Cold Shoe Interface
INPUT1 6.35mm Audio Input Jack(Right)
INPUT1 XLR Audio Input Jack (Right)
INPUT1 6.35mm Audio Input Jack(Left)
INPUT1 XLR Audio Input Jack(Left)
Locking Plate
1/4 Screw Bolt
3.5mm INPUT2 Mono Input Jack(Right)
3.5mm INPUT2 Stereo Audio Input Jack
3.5mm INPUT2 Mono Input Jack(Left)
INPUT1 Power Source Switch(Right)
INPUT1 Power Source Switch(Left)
INPUT1 Phantom Power Switch
INPUT2 Power Source Switch(Right)
1
2
3
4
5
6
7
8
9
15
16
17
18
19
20
21
22
23
24
25
26
27
7
653 42
17 18 19
1
1
8
9
10
14
15
16
20 21 24
23
22
25 26 27
11
12
13
10
11
12
13
14
INPUT2 Power Source Switch(Left)
INPUT2 3V Power Switch
9V Battery Holder
Left Gain-Control Knob
Right Gain-Control Knob
Audio Output Jack
Auxiliary Input Interface
1/4 Screw Hole
3/8 Screw Hole
Real-time Monitoring Jack
Mono/Stereo Switch
Power Indicator Light
Power Switch
3
