TPA 250 FUSE PANEL
SETUP AND OPERATION MANUAL
PRODUcT SPEcIFIcATIONS - PAGE 11
Section 6: Product Specications
6.1 Electrical Specications
NOTICE
USE BUSSMANN TPA TYPE FUSES ONLY.
FUSES MUST CARRY A 10kA INTERRUPT RATING.
TABLE 5. TPA 250 SERIES FUSE PANEL SPECIFICATIONS
MODELS:
016-2121-10
016-2123-10
016-2125-10
016-2127-10
MODELS:
016-2122-10
016-2124-10
016-2126-10
016-2128-10
Type of Input Single Input Dual Input (A/B)
Circuits 12 12 (6A/6B)
Input Voltage (+/- 0%) -42 to -60V DC -42 to -60V DC
Input Current 250A Max 250A Max
Short Circuit Withstand 10kA 10kA
Maximum Fuse Size 50A TPA 50A TPA
Maximum Per Circuit Current 40A 40A
Max Operating Altitude 2000 m 2000 m
Max Ambient Temperature 50º C 50º C
Width 17 in. 17 in.
Height 1.75 in. 1.75 in.
Depth (Not Including Lacing Bar Kits) 18 in. 18 in.
Weight 8.5 lbs. 8.5 lbs.
UL File Number E473904 E473904
UL Standard ANSI/UL 60950-1 ANSI/UL 60950-1
