TPA 250 FUSE PANEL
SETUP AND OPERATION MANUAL
PRODUcT SPEcIFIcATIONS - PAGE 17
TPA 250 FUSE PANEL
SETUP AND OPERATION MANUAL
PAGE 17
Appendix B: Supported Lugs For Termination
TABLE 6. CHASSIS GROUND CONNECTIONS
WIRE GAUGE LUG BARREL TYPE COMM/NET PART
NUMBER
MANUFACTURER MANUFACTURER PART
NUMBER
CRIMP DIE REQUIRED (HYDRAULIC)
#4 AWG Long 538-085-10 Burndy YAZV4C2TC14FX Burndy U4CRT, W4CRT, W4CVT, X4CRT
TABLE 7. INPUT CONNECTIONS
WIRE GAUGE LUG BARREL TYPE COMM/NET PART
NUMBER
MANUFACTURER MANUFACTURER PART
NUMBER
CRIMP DIE REQUIRED (HYDRAULIC)
#2 AWG Short; narrow tongue 538-173-10 Burndy YAV2CL2NT14FX Burndy U2CRT, W2CVT, W2CRT, X2CRT
#2 AWG Standard 538-158-10 Burndy YAV2CL2TC14FX Burndy U2CRT, W2CRT, W2CVT, X2CRT
#2 AWG Long 538-089-10 Burndy YAZV2C2TC14FX Burndy U2CRT, W2CVT, W2CRT, X2CRT
1/0 Short 538-350-10 Burndy YAV25L2TC14FX Burndy U25RT, W25VT, W25RT, X25RT
1/0 Standard 538-125-10 Burndy YAV25L2NT14FX Burndy U25RT, W25VT, W25RT, X25RT
1/0 Long 538-091-10 Burndy YAZV252TC14FX Burndy U25RT, W25VT, W25RT, X25RT
1/0 Long; narrow tongue 538-260-10 Burndy YAZV252NT14FX Burndy U25RT, W25RT, X25RT, W25VT
2/0 Short 538-357-10 Burndy YAV26L2TC14FX Burndy U26RT, W26VT, W26RT, X26RT
2/0 Standard 538-313-10 Burndy YAV26L2NT14FX Burndy U26RT, W26VT, W26RT, X26RT
2/0 Long 538-114-10 Burndy YAZV262TC14FX Burndy U26RT, W26VT, W26RT, X26RT
4/0 Short 538-410-10 Burndy YAV28L2TC14FX Burndy U28RT, W28VT, W28RT, X28RT
4/0 Standard 538-124-10 Burndy YAV28L2ENT14FX Burndy U28RT, W28VT, W28RT, X28RT
4/0 Long 538-122-10 Burndy YAZV282TC14FX Burndy U28RT, W28VT, W28RT, X28RT
