To Next PageTo Next PageHow to fix a Commercial Electric TV Mount that is not level?
First, verify that the wall plate is level by using the bubble level provided. If it isn't, adjust the wall plate until it is level. Next, check the TV plate. If the TV plate is not level, use a hex wrench to loosen the two leveling bolts on the rear TV plate. Hold the TV to make adjustments until it is level, then tightly fasten the leveling bolts.
General| Brand | Commercial Electric |
|---|---|
| Model | XD2615-1A |
| Material | Steel |
| Color | Black |
| Mounting Pattern | Universal |
| VESA Compatibility | 200x100mm, 200x200mm, 300x200mm, 400x200mm, 400x400mm |
| Maximum TV Weight | 88 lbs (40 kg) |
| Load Capacity | 88 lbs (40 kg) |
| Wall Compatibility | Wood studs, concrete |
