INSTRUCTIONS & DIAGRAMS
12
Number Description Parameters
1 LCD Screen Display with Cover
128*64pc
16*4 Characters
2 Keyboard Esc, Up, Down, Enter
3 AC Output
Four Lines ( 3Phase and Ground
Line )
Red/Yellow/Blue/Yellow_Green
Colour IP65
4 AC/Battery Input
Four Line ( 3Phase and Ground Line
) Red/Yellow/Blue/Yellow_Green
Colour IP65
5 DC Input Negative and Positive MC4 /IP68
6 Fan for Wind Cooling IP68
7 Communication
RS485 /RS232
IP65
8 Well /Borehole Sensor IP65
9 Tank Sensor IP65
10 Power On/ O Control
Inverter Startup: The LED On Stop:
The LED O IP65
11 The Hole for Installation 8-10mm
12
The slide plate to keep cooling air
be Vertically
To Next Page
