SOLAR PUMPING INVERTER I USER MANUAL
13
Example:
Total Height (H) of a Well is 100m, water depth is 90m.
H3: Bottom of well to the pump inlet is 10m.
H2: 40m.
H1: 40m.
AC Input/Output
Do not connect a breaker between inverter AC output connector with pump.
AC Output to 3 Phase Pump Connection:
Red Colour Yellow Colour Blue Colour Yellow_Green
Pump-U Phase Pump-V Phase Pump-W Phase Ground
Note: If the pump water flow is minimal, please try to change any 2 wire of 3 phase to
change the forward or reverse running direction.
AC Output to Single Phase Pump Connection:
Please refer to the 17-19.
AC Input connection:
AC Input to Solar Pumping Inverter
Red Colour Yellow Colour Blue Colour Yellow_Green
AC-U Phase AC-V Phase AC-W Phase Ground
