SOLAR PUMPING INVERTER I USER MANUAL
23
On/O Button
Startup:
Press Down
The light on
Shut Down:
Press Up
The light O
Remark:
If the solar pump inverter common wire is connected to the single-phase pump common wire incorrectly, there are 3
issues which can arise,
a. Pump will run, but it will be over the rated current.
b. Pump is heat, and it will stop running or burnout after 15 - 30 minutes.
c. Water flow is low.
Is the Solar water pump inverter and the single-phase pump common wire are connected correctly, but the running
wire and the starting wire are connected incorrectly, the pump can run in reverse, leading to low water flow.
Solar Pump Inverter single phase or three phase 220v selection setting.
Check the solar pump inverter AC output phase whether it is single phase. If yes, continue to the installation.
If no, enter the settings Menu to set the inverter AC output phase to single phase 220V. After changing the setting,
switch the power o, so the settings will be saved. If the solar pump inverter AC output is 3 phase 220v, and it
connects with the single phase 220v pump, it will show "phase lost".
The solar pump inverter single phase and three phase AC output steps as follow,
HSPH5500H
ID: 9792
On(Working)
14:24 07/16/19
Enter Into
Setting Menu
9 5 7 8
Verify the PW
AC Pump Phase
Single
Three
State Now: Single
To Next Page
