Stop Type
Coast: The inverter stop output immediately while the stop command is
valid.
Decelerate: The inverter output frequency decrease by the Deceleration
time while the stop command is valid.
V/F Curve
Linear
P1.3: Power 1.3
1.5 : Power 1.5
1.7: Power 1.7
2: Power 2.0
Phase Lost Detect Setting
Det time: Detect time
Det Ampere: 30% , if one of ac output phase’s current is lower than the
other phase by 30%, and continue throughout the detection periosl, the
inverter will stop.
AC Max Output Frequency
Set the Max output Frequency, Range from 15 to 60Hz
NOTE: Please check your pump parameters. If the pump is 50Hz, but you
set inverter AC output Max 60Hz, the pump will be damaged!
AC Max Output Voltage
Set the Max output Voltage. Invalid for 220V inverter.
NOTE: Please check your pump parameters. If the pump is 380V, but you
set inverter AC output voltage Max 440V, the pump will be damaged!
AC Output Phase
Adjust the Phase sequence to make the pump reverse or forward running.
AC OUTPUT Maximum Current
Maximum setting value is 2 times of rated current . Default value is 1.5 times
of rated current
AC Pump Phase
The configuration for 0.75KW-2.2KW inverter only.
Single: the AC pump is Single phase
Three: the AC pump is Three phase
Inverter Stop
Coast
Decelerate
Now: Coast
Ac Out Max
50
Frequency (Hz)
Ac Output
Max Voltage
389
323~506V
Phase Sequence
Forward
Reverse
State Now: FWD
Ac Output
021
Maximum Ampere
AC Pump Phase
Single
Three
State Now: Single
VF Curve Set
Linar
P1.3 1.5 1.7 2
Now: Power 2
AC Out Phaselost
Det time 1.0 S
Det Ampere: 30%
To Next Page
