26
SYSTEM SETTINGS
26
Power Up
Make sure there is power going to the pump drive (solar panels, generator
or mains power) and the screen is on the main display. If the screen is not on
the main display, press the "ESC" or “UP” button until it shows:
Password
Some versions of the pump drive software require a dierent password
to access some settings. If a password is required to access a particular
setting in some software versions, the setting won’t appear in the main
System Setting Menu. The password will be listed with the title for each
setting on the following pages.
To access the Main Menu of settings:
• Press the Up button until the screen shows the page with the model
number of the pump drive.
• Press Enter, then input the password 0000:
• Use the up and down buttons to adjust the highlighted number,
press enter to highlight the next digit.
• Once all digits of the password are set, press Enter again to go
ahead.
If the password does not work, the super password is 9590.
System Setting Menu (use password 0000)
This will bring you into the System Menu, the settings listed here don't
require a dierent access password. Use the Up and Down buttons to
navigate through the list of settings, once a desired setting is highlighted
press Enter to select the setting to adjust it.
The pump must be stopped before changing any settings using the on/o
button on the drive.
Working Time
The Working Time option allows setting a window of time for the pump
daily operating hours in 24-hour time. By default, the pump is allowed to
operate at any time of the day or night with “0:00” and “23:59” set.
For a ‘hybrid’ solar pump where mains power is available, one might wish
to set a window of time to match the sun hours – if there is no need for the
pump to operate after dark. For example, to pump only between 8am to
6pm, set “8:00” and “18:00”.
If you wish to set a time window, it is important to check the time is set
correctly on the pump drive. In the Main settings menu, scroll down to
Clock or Time Calibrate and press Enter. Using the directional buttons,
change the time and date to your local time - press Enter for each section
when complete.
HSPH5500H
ID: 9792
On(Working)
14:24 07/16/19
Enter Into
Setting Menu
0 0 0 0
Verify the PW
System Setting
1. Working Time
2. Hybrid/Stop
3. Dry-Run Detect
4. Tank Sensor
5. 5. Borehole Sensor
6. Time Calibrate
7. System PW Set
8. Tank Timer
9. Borehole Timer
10. Esc Key Fun
11. Factory Reset
