SOLAR PUMPING INVERTER I USER MANUAL
35
Display Note
“W:Solar C-Sensor“ Solar current sensor issue warning
“W:AC C-Sensor“ AC input current issue warning
“W:Capacitor Life“ Replace the capacitor warning
“W: U-Ph C-Sensor“ AC output U phase current sensor issue warning
“W:V-Ph C-Sensor“ AC output V phase current sensor issue warning
“W:W-Ph C-Sensor“ AC output W phase current sensor issue warning
“E:Over Voltage“ Solar input over voltage error
“E:AC Out O-A“ AC output over load error
“E:AC Out Short-C“ AC output over max current of IGBT or AC output phase short circuit error
“E: Over Temp“ Inverter over max temperature error
“E:Power Supply“ Hardware power supply error
“E:Over Load“ Solar input power over max power of inverter error
“E:Out Phase Lost“ AC output 3phase phase lost error
“E:AC Out P_G S-C“ AC output phase to ground short circuit
Error Code
Beep
Alarm
Times
Reason
E1 1 Solar input power over max power of inverter error
E2 2 Solar input over voltage Error
E4 3 AC output over current of IGBT or AC output phase short circuit error
E8 4 AC Output over load error
E16 5 Inverter over max temperature error
E32 6 Hardware power supply error
E64 7 AC output 3phase phase lost error
E128 8 Software error
E256 9 Voltage booster error
E512 X X
E1024 10 AC output phase to ground short circuit
E2048 11 AC output current sensor error
E4096 12 Capacitor over life time error
