COMMUNITY PROFESSIONAL LOUDSPEAKERS
333 East 5th Street, Chester, PA USA 19013-4511 TEL (610) 876-3400 FAX (610) 874-0190
www.loudspeakers.net
MVP35 [04-17-02]
Specifications subject to change without notice.
MVP35 Page 2 of 2
The loudspeaker system shall be a two-way, full-range bass reflex trapezoidal design with one 15” woofer and one 3/4”
exit HF driver with a non-metallic diaphragm mounted to a 90° H x 40° V molded horn. Drivers shall be connected
to an integral crossover with a crossover frequency of 2 kHz and a HF driver over-current and thermal protection cir-
cuitry. There shall be two 1/4" phone jacks and two locking connectors. The loudspeaker enclosure shall be black car-
peted MDF construction with a 16 gauge perforated steel grille. The system shall have an amplitude response of 70
Hz to 14 kHz (+/- 3.6 dB), input capability of 40V RMS, 95 dB sensitivity at one meter and 2.83 V/8 ohms nominal
impedance. The nominal dispersion shall be 90° H x 40° V from 1 kHz to 12.5 kHz. The loudspeaker shall be 23.8”
(606.5 mm) H x 17.5” (445 mm) W (front) x 13.1” / 333 mm W (rear) x 15” (380 mm) D and weigh 46 lbs (21 kg).
LIMITED WARRANTY
Community MVP loudspeakers are guaranteed to be free from defects in materials and workmanship from the original
date of sale for a period of five years in the U.S.A and worldwide. This warranty is automatically transferable to any and
all owners during the specified period. For complete warranty information, consult the product owners manual or call
(610) 876-3400 for a copy.
ARCHITECTS AND ENGINEERS SPECIFICATIONS
Frequency Response Impedance
Beamwidth Axial Q
Frequency in Hertz
Degrees
Frequency in Hertz
Q
Frequency in Hertz
Frequency in Hertz
dB SPL
Ohms
MVP35
TWO-WAY TRAPEZOIDAL LOUDSPEAKER WITH 90° X 40° HF HORN
20,000
20,000
20,000
20,000
SIDE
VIEW
FRONT
VIEW
REAR
VIEW
TOP
VIEW
BOTTOM
VIEW
D
IMENSIONS
