COMPANION COMP490 - Page 6

6
Step 7
Setthesmokestackontopofthecabinet
andlineitupwiththematchingholes.
InsertthreeM5x16mmboltsthrough
smokestackbaseandintocabinet.Secure
withthreeM5mmnuts.
Step 8
Lineupthesidehandlewiththematching
holesoneachsideofthecabinetasshown.
Thehandlesmustbepositionedupright
withtheboltholesonthebottomasshown.
InserttwoM5x16mmboltsandgaskets
fromtheoutsideandthreadintotheholes
inthesideofthecabinetasillustrated.
Tightensecurely.Completestepsforboth
sidesofthecabinetassembly.
Step 9
InserttheWoodChipBoxrackintothe
bottomofthesmoker.Thefeetoftherack
sitinthefourindentationsinthebottom.
Step 10
SettheWoodChipBoxontotherack.Make
sureitisseatedproperlyandsecurelyin
thecentreoftherack.Placethelidonthe
WoodChipBox.
