COMPANION COMP490 - Carton Contents Checklist; Hardware Bag Contents

3
PARTS DIAGRAM
Inspectcontentsoftheboxto
ensureallpartsareincluded
andundamaged.
CARTON CONTENTS
Makesureyouhaveallitems
listedunderCARTON
CONTENTSandHARDWARE
BAG CONTENTS
beforeyoubeginthe
assemblyprocess.
1.DoorHandlex1
2.TemperatureGaugeAssemblyx1
3.SmokeStackx1
4.CookingGrillsx4
5.SmokerBodyx1
6.WaterPanx1
7.WoodChipBoxLidx1
8.WoodChipBoxx1
9.WoodChipBoxRackx1
10.BurnerAssemblyx1
11.SideHandlesx2
12.ControlPanelAssemblyx1
13.Legsx4
14.ZipTiex1
15.S-Hookx1
 Use&CareGuidex1
 HardwareBagx1
HARDWARE BAG CONTENTS
Quantity
HeatResistantWashers(DoorHandle)x2
M5x16mmBoltsx7
M6x16mmBoltsx15
M4x25mmBoltsx2
M5mmNutsx3
#10Washersx3
Gasketsx7
Heat Resistant Washers
(Door Handle) x 2
M6 x 16 mm Bolts x 15
M4 x 25 mm Bolts x 2 M5 mm Nuts x 3 #10 Washers x 3
M5 x 16 mm Bolts x 7
Gaskets x 7
Four adjustable
chrome plated
steel cooking
grills
Wood chip pan
Porcelain coated
water pan
Appliance style
magnetic closure
Powerful 14,500 BTU
brass burner
Rotary
igniter
POL regulator
& hose
not included
