Compaq 6830s - Notebook PC - Page 107

Phillips PM2.0×3.0 screw
Color Quantity Length Thread Head diameter
Silver 10 3.0 mm 2.0 mm 4.5 mm
Where used: 2 screws that secure the optical drive bracket to the optical drive
Where used: 8 screws that secure the display hinges to the display assembly
Phillips PM2.0×3.0 screw 99
