Compaq 6830s - Notebook PC - Page 108

Phillips PM2.0x4.0 screw
Color Quantity Length Thread Head diameter
Black 5 4.0 mm 2.0 mm 4.5 mm
Where used: 1 screw that secures the Blueotooth module to the base enclosure
Where used: 4 screws that secure the optical drive connector board to the system board
100 Chapter 7 Screw listing
