Installing a System into a Cabinet 15
WARNING:
1. Make sure that all other hardware in the cabinet is pushed in
and attached.
2. The system is very heavy. Do not attempt to lift it manually.
Use a material lift or other mechanical device.
1.
Align the narrow segment of the slides attached to the system with the
slides attached to the cabinet.
2.
Depress the green release button on each side and slide the system
completely into the cabinet.
To Next Page
