Compaq AlphaServer ES40 - Installing the Interlock System

16 Compaq AlphaServer ES40 Rackmount System Installation Guide
1.8 Installing the Interlock System
The interlock system ensures cabinet stability by allowing only one
system drawer at a time to be pulled out of the cabinet. The stabilizer
bracket and actuator latch only work in a cabinet equipped with the
interlock system.
Figure 1–8 Installing the Interlock System
PK0250
1
3
6
2
4
5
7
8
1
