Compaq Armada 1500 Service Manual Addendum

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Addendum to Compaq Armada 1500
Maintenance and Service Guide
Addendum 255318-001 to Guide 284820-001 9
Table 4-4
Standard and Optional Boards
Description Model(s) Spare Part Number
LED Board
11.3 inch display LED board 1510, 1510DM, 1520, 1520D,
1520DM
254958-001
12.1 inch TFT display LED board 1550T, 1550DMT, 1580DT,
1580DMT, 1585DMT
255049-001
12.1 inch STN display LED board 1530, 1530D, 1530DM,
1535DM, 1540D, 1540DM,
1560, 1560D, 1560DM
255189-001
12.1 inch TFT display LED board 1590DT, 1590DMT,
1592DT,1592DMT
255190-001
I/O Fixture Connector
All models 254956-001
DC/DC Converter Board
All models (except MMX
models)
254976-001
DC/DC Converter Board,
2.5 / 2.45 / 2.9v
All MMX models except as
noted below
255161-001
DC/DC Converter Board, 1.8v Armada 1592 255262-001
Audio Board
All models 254957-001
System CPU Board
120-MHz processor 1510, 1510DM 254949-001
133-MHz processor 1520, 1520D, 1520DM, 1550T,
1550DMT
255010-001
133-MHz processor with MMX 1530, 1530D, 1530DM,
1535DM
255129-001
150-MHz processor 1580DT, 1580DMT, 1585DMT 255071-001
150-MHz processor with MMX 1540D, 1540DM 255187-001
166-MHz processor with MMX 1560, 1560D, 1560DM 255310-001
166-MHz processor with MMX 1590DT, 1590DMT 255188-001
233-MHz MMX processor 1592DT, 1592DMT 255246-001
