Using the Internal Modem 8-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: WBuoy Saved by: Jennifer Hale Saved date: 10/07/98 5:46 PM
Part Number: 387792-001 File name: ch08.doc
Modem Compatibility
The internal modem is compatible with the following data and
facsimile communications standards:
Command Set
Hayes AT command set (EIA/TIA 602)
Data Communications
ITU V.90 (speeds higher than 33600 bps)
ITU V.34 Annex (K56flex or 33600 bps)
ITU V.34 (28800 bps)
ITU V.32 (19200 bps)
ITU V.32bis (14400 bps)
ITU V.32 (9600 bps)
ITU V.23 (1200/75 bps)
ITU V.22bis (2400 bps)
ITU V.22 (1200 bps)
ITU V.21 (300 bps)
Bell 212A (1200 bps)
Bell 103 (300 bps)
Facsimile Communications
ITU V.17 (14400 bps)
ITU V.29 (9600 bps)
ITU V.27ter (4800 bps)
ITU V.21 Ch2 (300 bps)
Class I facsimile extensions to the Hayes AT command set
(EIA/TIA 578)
Support for Group III facsimile machines
Data Compression
ITU V.42bis
MNP 5
Error Control
ITU V.42 (LAPM)
MNP 2-4
