9-2 Additional Features
Writer: Jennifer Hale Saved by: Jennifer Hale Saved date: 10/07/98 5:55 PM
Part Number: 387792-001 File name: Ch09.doc
Identifying Audio Connections
The computer has three audio connections:
1 stereo speaker/headphone jack
2 microphone jack
3 stereo line-in jack
CAUTION:
Use only a 3.5-mm stereo plug in the stereo
speaker/headphone jack. A mono plug can result in damage
to the computer.
IMPORTANT:
A mono electret condenser microphone is
recommended. Plugging a stereo microphone in the mono
microphone jack is acceptable, but the left channel will be
recorded on both the left and right channels.
