Compaq Armada E500 Series Description

Product Description 1-21
Table 1-7
Keyboard Components (continued)
Item Component Function
1 Hard drive light (green) Turns on when the hard drive is being
accessed.
2 MultiBay light (green) Turns on when a MultiBay device is being
accessed or a battery pack in the MultiBay
is charging or waiting to be charged.
3 Num lock light Turns on when the numeric lock function is
on.
4 Caps lock light Turns on when the caps lock function is on.
5 Scroll lock light Turns on when the scroll function is on.
6 Scroll lock key Turns on the scroll function.
7 Num lock key Turns on the numeric lock function.
8 Pointing stick Moves the mouse cursor.
9 Stereo speakers Produce stereo sound.
10 Left and right mouse
buttons
Function like left and right mouse buttons
on an external mouse.
11 Fn key Used with hotkeys to perform preset hotkey
functions.
12 F1 through F12
function keys
Perform preset functions.

Compaq Armada E500 Series Specifications

General

Processor	Intel Pentium III
Chipset	Intel 440BX
Optical Drive	24x CD-ROM or DVD-ROM
Networking	10/100 Ethernet
Wireless	Optional 802.11b
RAM	Up to 512 MB
Display	14.1-inch TFT, 1024x768 resolution
Graphics	ATI Rage Mobility with 8 MB
Ports	USB, Parallel, Serial, VGA, PS/2, Infrared
Battery	Lithium-Ion
Operating System	Windows 98, Windows 2000
Storage	6 GB - 12 GB Hard Disk Drive
Battery Life	Approximately 2-3 hours
