Compaq Armada E500 Series

Product Description 1-23
Table 1-8
Bottom Components
Item Component Function
1 Mini PCI slot cover Contains the mini PCI modem or network
interface card.
2 Battery release latch Releases the battery from the battery bay.
3 Hard drive cover
release latch
Releases the hard drive cover.
4 Hard drive cover screw Secures the hard drive cover.
5 Hard drive cover Covers the hard drive bay.
6 Diskette drive release
latch
Releases the device from the DualBay on
the Armada E500.
Releases the diskette drive bezel from the
Armada V300.
7 MultiBay release latch Releases the MultiBay device.
