2ā8 Maintenance and Service Guide
External component identification
Right-side components
Item Component Function
1
Optical drive Reads optical discs and, on select models, also writes to optical discs.
2
Optical drive light Blinking: The optical drive is being accessed.
3
USB ports (2) Connect optional USB devices.
4
RJ-11 (modem) jack (select models only) Connects a modem cable.
5
Security cable slot Attaches an optional security cable to the computer.
ā
The security cable is designed to act as a deterrent, but it may
not prevent the computer from being mishandled or stolen.
