Compaq CQ70 - Page 23

3–4 Maintenance and Service Guide
Illustrated parts catalog
(11) System boards
UMA system board, GM45 (includes built-in modem, Digital Media Slot, HDMI port, and
replacement thermal material)
485218-001
UMA system board, GL40 (includes built-in modem, Digital Media Slot, HDMI port, and
replacement thermal material)
485219-001
Discrete system board, PM45 (includes built-in modem, Digital Media Slot, HDMI port, and
replacement thermal material)
488338-001
UMA system board, GL40 (includes built-in modem, Digital Media Slot, and replacement
thermal material)
494282-001
(12) Speakers (include left and right speakers and cables) 488383-001
(13) Audio board (includes audio board cable) 489120-001
(14) Processors (include replacement thermal material)
Intel Core2 Duo processors (6-MB L2 cache, 1066-MHz FSB)
T9400 2.53-GHz processr 492318-001
Intel Core2 Duo processors (3-MB L2 cache, 1066-MHz FSB)
■ P8600 2.4-GHz processor 492317-001
■ P8400 2.26-GHz processor 492316-001
■ P7350 2.0-GHz processor 501520-002
Intel Core2 Duo processors (2-MB L2 cache, 800-MHz FSB)
■ T5900 2.2-GHz processor 501522-002
■ T5800 2.0-GHz processor 501521-002
Intel Pentium Dual-Core processors (1-MB L2 cache, 667-MHz FSB)
■ T3400 2.16-GHz processor 501523-002
■ T3200 2.0-GHz processor 492319-001
Intel Celeron-M processors (1-MB L2 cache, 667-MHz FSB)
■ 585 2.16-GHz processor 492322-001
■ 575 2.0-GHz processor 492321-001
Intel Celeron-T processors (1-MB L2 cache, 667-MHz FSB)
■ T1700 1.86-GHz processor 501525-002
■ T1600 1.66-GHz processor 501524-002
(15) Modem module cable 489125-001
(16) Power connector cable 486637-001
(17) Optical drive connector 489127-001
(18) Base enclosures (include rubber feet)
For use only with computer models equipped with a built-in modem, Digital Media Slot, and
an HDMI port
489114-001
For use only with computer models equipped with a built-in modem and Digital Media Slot,
without an HDMI port
501252-001
Rubber Kit (not illustrated, includes 6 computer feet) 486623-001
(19) Battery, 6-cell, 2.20-Ah, 47-Wh 485041-003
(Continued)
Item Description Spare Part Number
