3–10 Maintenance and Service Guide
Illustrated parts catalog
Plastics Kit
Item Description Spare part number
Plastics Kit: 489112-001
1
WLAN module compartment cover (includes 1 captive screw, secured by a C-clip)
2
Memory module compartment cover (includes 2 captive screws, secured by C-clips)
3
Hard drive cover (includes 2 captive screws, secured by C-clips)
