6–2 Maintenance and Service Guide
Specifications
17-inch WXGA display specifications
Metric U.S.
Dimensions
Height 24.4 cm 9.6 in
Width 38.1 cm 15.0 in
Diagonal 43.2 cm 17.0 in
Number of colors Up to 16.8 million
Contrast ratio 200:1
Brightness 180 nits typical
Pixel resolution
Pitch 0.259 × 0.259 mm
Format 1440 × 900
Configuration RGB vertical stripe
Backlight CCFT
Character display 80 × 25
Total power consumption 6.5 W
Viewing angle +/-45° horizontal, +15/-35° vertical typical
