Maintenance and Service Guide 7–1
7
Screw listing
This section provides specification and reference information for the screws used in the computer. All screws listed
in this section are available in the Screw Kit, spare part number 486622-001.
Phillips PM2.5x5.0 screw
Where used: 1 screw that secures the optical drive to the computer
Where used: 2 screws that secure the keyboard to the computer
Color Quantity Length Thread Head diameter
Black 7 5.0 mm 2.5 mm 4.0 mm
