Compaq CRT Monitor s7500 User Manual

DATE: 2002. 04. 15.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R737 0RN0560H609 0.56 1/2W 5 TA52
R738 0RN0560H609 0.56 1/2W 5 TA52
R740 0RD0271A609 2.7 OHM 1/2 W (7.0) 5% TA52
R741 0RD1000Q609 100 1/4W(3 5% TA52
R742 0RD4702Q609 47K 1/4W(3 5% TA52
R743 0RD2701Q509 2.7K OHM 1/4 W(3.4) 2% TA52
R744 0RX3900J609 390 OHM 1 W 5% TA52
R745 0RD4702Q609 47K 1/4W(3 5% TA52
R746 0RD2201Q609 2.20K 1/4W(3 5% TA52
R747 0RD3001Q609 3K 1/4W(3 5% TA52
R748 0RD4702Q609 47K 1/4W(3 5% TA52
R749 0RD2201Q609 2.20K 1/4W(3 5% TA52
R750 0RD3001Q609 3K 1/4W(3 5% TA52
R751 0RX3900J609 390 OHM 1 W 5% TA52
R752 0RD2201Q609 2.20K 1/4W(3 5% TA52
R753 0RD3001Q609 3K 1/4W(3 5% TA52
R754 0RX4300K607 430 OHM 2 W 5% TA62
R755 0RD0471Q609 4.70 1/4W(3 5% TA52
R756 0RD2202A609 22K OHM 1/2 W (7.0) 5% TA52
R757 0RD0222A609 22 OHM 1/2 W (7.0) 5% TA52
R758 0RN1303F409 130K 1/6W 1% TA52
R759 0RD1202Q509 12K OHM 1/4 W (3.4) 2% TA52 LPD CDT
R759 0RD1302Q509 13K OHM 1/4 W (3.4) 2% TA52 TECO CDT
R760 0RD5103Q609 510K 1/4W(3 5% TA52
R761 0RD3001Q609 3K 1/4W(3 5% TA52
R762 0RD3001Q609 3K 1/4W(3 5% TA52
R763 0RD3001Q609 3K 1/4W(3 5% TA52
R764 0RD6201Q609 6.20K 1/4W(3 5% TA52
R766 0RD0752Q609 75 1/4W(3 5% TA52
R768 0RD6803A609 680K OHM 1/2 W (7.0) 5% TA52
R771 0RD3301Q609 3.30K 1/4W(3 5% TA52
R772 0RD2702Q509 27K OHM 1/4 W(3.4) 2% TA52
R773 0RD4302A609 43K OHM 1/2 W(7.0) 5.00% TA52 LPD CDT
R773 0RD2402A609 24K OHM 1/2 W (7.0) 5% TA52 TECO CDT
R775 0RD4701Q609 4.70K 1/4W(3 5% TA52
R778 0RD4301Q609 4.30K 1/4W(3 5% TA52
R779 0RD4701Q609 4.70K 1/4W(3 5% TA52
R782 0RD3301A609 3.3K OHM 1/2 W(7.0) 5.00% TA52
R784 0RD1000Q609 100 1/4W(3 5% TA52
R789 0RD6800Q609 680 1/4W(3 5% TA52
R793 0RD4702Q609 47K 1/4W(3 5% TA52
R797 0RD1501Q609 1.50K 1/4W(3 5% TA52
R798 0RD2001Q609 2K 1/4W(3 5% TA52
R799 0RD1502Q609 15K 1/4W(3 5% TA52
R801 0RD1802Q609 18K 1/4W(3 5% TA52 LPD CDT
R801 0RD1602Q609 16K 1/4W(3 5% TA52 TECO CDT
R802 0RD3302Q609 33K 1/4W(3 5% TA52
R803 0RD2001Q609 2K 1/4W(3 5% TA52
R805 0RD2001Q609 2K 1/4W(3 5% TA52
R806 0RD4702Q609 47K 1/4W(3 5% TA52
R808 0RD6802Q609 68K 1/4W(3 5% TA52
R809 0RMZTWD001G RWR SMART 1OHM 5 W 5% PD TYPE
R813 0RD4302A609 43K OHM 1/2 W(7.0) 5.00% TA52
R814 0RD1002Q609 10K 1/4W(3 5% TA52
R816 0RN3601F409 3.6K 1/6W 1 TA52
R818 0RN2202F409 22K 1/6W 1% TA52
R819 0RD4702Q609 47K 1/4W(3 5% TA52
R821 0RD3001Q609 3K 1/4W(3 5% TA52
R822 0RX0122K607 12 OHM 2 W 5% TA62
R823 0RX0122K665 12 OHM 2 W 5% SF
R824 0RX0122K665 12 OHM 2 W 5% SF
R831 0RD1002Q609 10K 1/4W(3 5% TA52
DATE: 2002. 04. 15.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R901 0RD4703A609 470K OHM 1/2 W (7.0) 5% TA52
R903 0RD5600A609 560 OHM 1/2 W (7.0) 5% TA52
R904 0RX1503K607 150K OHM 2 W 5% TA62
R905 0RD2201Q609 2.20K 1/4W(3 5% TA52
R906 0RD6200Q609 620 1/4W(3 5% TA52
R907 0RN0220H609 0.22 1/2W 5% TA52
R908 0RN0220H609 0.22 1/2W 5% TA52
R910 0RX9102J609 91K OHM 1 W 5% TA52
R911 0RD5602Q609 56K OHM 1/4 W(3.4) 5.00% TA52
R912 0RX9102J609 91K OHM 1 W 5% TA52
R925 0RB0120K607 0.12 OHM 2 W 5% TA62
R941 0RN0220H609 0.22 1/2W 5% TA52
R944 0RD4700A609 470 OHM 1/2 W (7.0) 5% TA52
R945-1 0RD4701Q609 4.70K 1/4W(3 5% TA52
R951 0RN0220H609 0.22 1/2W 5% TA52
R952 0RD4702A609 47K OHM 1/2 W (7.0) 5% TA52
R953 0RX4700J609 470 OHM 1 W 5% TA52
R954 0RD4701Q609 4.70K 1/4W(3 5% TA52
R955 0RD4701Q609 4.70K 1/4W(3 5% TA52
R956 0RD4702Q609 47K 1/4W(3 5% TA52
R957 0RD0472A609 47 OHM 1/2 W (7.0) 5% TA52
R960 0RD2200A609 220 OHM 1/2 W (7.0) 5% TA52
R967 971-0016 TIN HDC 0.60H
F901 0FZZTTH001D TIME LAG HBC 3.15A/250V,215 3.
J27 0RD0471Q609 4.70 1/4W(3 5% TA52
J59 0RD1000Q609 100 1/4W(3 5% TA52
J99 0RD1001Q609 1K 1/4W(3 5% TA52
J103 0RD1501Q609 1.50K 1/4W(3 5% TA52
RL901 6920TBB005A ALA2PF12 MATSUSHITA 250V 5A 12
SC301 6620TBD004A GZS10-2-101 DUOLING(SANLING) 1
SC901 6620TKB002B SA-4S HUA JIE AC UNIVERSAL 3PI
SG301 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SG302 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SG303 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SG304 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SG305 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SG701 6918TRT005A SSG-102-A0,1KV SMART RADIAL TA
SW201 140-058D SKHV10911A LGEC NON 12 20 HORI
SW202 140-058D SKHV10911A LGEC NON 12 20 HORI
SW203 140-058D SKHV10911A LGEC NON 12 20 HORI
SW204 140-058D SKHV10911A LGEC NON 12 20 HORI
T1 6631T11005D 1P W-T 520MM UL 1015 AWG 22 CB
T701 6174T11003E “1054A,CB777G LG-PHILIPS 17”””
T702 6170TCZ006A EE2218 2.3 MH D/FOCUS(CB775C),
T703 6170TCZ001D EI2218 4.0MH H-DRIVE,EB770G
T901 6170TMZ132A EER3541 150UH V-16PIN EB770G S
TH901 6322B00002B MZ72-9RM290V GAOLI 9OHM 20% 2P
TH902 6322TA080BA SCK-084 THINKING 8 ohm 15% 264
X401 6202TTB003B HC-49/U HARMONY RADIAL 12MHZ 3
