Compaq Evo N600c - Technical Specifications

QuickSpecs
Compaq Evo Notebook N600c
DA-10886 World Wide — Version 2 — September 20, 2001 19
Technical Specifications
System Unit
Dimensions (HxWxD)
14.1-inch TFT panel display 1.2 x 12.1 x 9.8in/3.1 x 30.7 x 25.0 cm
Weight
14.1-inch LCD, weight saver, 1
SODIMM
4.8 lbs/2.1 kg*
14.1-inch LCD, CD-RW, DVD or
CD-ROM, 1 SODIMM
5.5 lbs / 2.5 kg*
Note: * = Weight varies by configuration.
Stand-Alone Power
Requirements
Nominal Operating Voltage
(Li-Ion)
14.4V (8-cell)
Average Operating Power 15.8W
Peak Operating Power 38W
Power in suspend mode <800 mW
Power in hibernation mode <100 mW
Power Supply
Rated Input Voltage 90 to 264 VAC (auto-switching)
Rated Input Current < 60W
Rated Frequency 47 to 63 Hz
Temperature
Operating 50° to 95° F/10° to 35° C
Non-operating –4° to 140° F/–20° to 60° C
Relative Humidity
Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, 101.6°F/38.7°C
Maximum wetbulb temperature
Shock
Operating 10 G, 11 ms, half-sine
Non-operating 60 G, 11 ms, half-sine
Vibration
Operating 0.5 G zero-to-peak, 10 to 500 Hz, 0.25 oct/min
sweep rate
Non-operating 1.0 G, zero-to-peak, 10 to 500 Hz, 0.5 oct/min
sweep rate
Operating 0 to 10,000 ft/(0 to 3,048 m)
Maximum Altitude
(unpressurized)
Non-operating 0 to 30,000 ft/(0 to 9,144 m)
Dimensions (HxW) 11.22 x 8.46 in/28.5 x 21.5 cm
Diagonal Size 14.1 in/35.81 cm
14.1-Inch Color TFT XGA
Display
Mounting
Internal Panel Supports, Side Mounted
Number of Colors Up to 16.8M
Contrast Ratio 150:1
Brightness 120nt typ
Pixel Resolution Pitch 0.264 x 0.264 mm
Format 1024 x 768
Configuration RGB stripe
Backlight Edge Lit
Character Display 80 x 25
Total Power Consumption 4.2W
