QuickSpecs
Compaq M720 CRT Monitor
DA-10999 World Wide — Version 1 — October 15, 2001
2
S
PECIFICATIONS
(continued)
Tilt Base (up/down) 13° up/5° down
Swivel ± 45° left/right
User Controls Brightness, Contrast Yes
Size and Positioning Yes
Pincushion (barrel) Yes
Trapezoid Yes
Tilt (rotation) Yes
Color temperature (6500K/9300K) Yes
Parallelogram No
Pincushion Balance No
Pinbalance No
Individual color control No
Moiré Cancellation Yes
Convergence No
Vertical Linearity Yes
Display Timing Yes
OSD Lock/Unlock Yes
Serial Number Display No
Degauss Yes
Factory Reset/Recall Yes
AssetControl Yes
Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.
Pixel Clock Speed 110 MHz
Input Impedance 75 ohms
Horizontal Frequency 30 to 70 KHz
Vertical Frequency 50 to 160 Hz
Power Supply 90 to 132 & 195 to 265 VAC, 47.5 to 63 Hz Universal Auto-Sensing
Maximum Power Rating 90 Watts
Power Saver State < 3W
Synch Input TTL separate synch
Signal Cable Captive 15-pin D-sub video cable
Dimensions (W x D x H) 398 x 412 x 400 mm (15.6 x 16.2 x 15.7 in)
Weight (Packaged/Unpackaged) 17.5 kg/15 kg (38.6 lbs/33.1 lbs)
Operating Temperature 10° to 35° C (50° to 95° F)
Operating Humidity (non-condensing) 10% to 80%
