Compaq MV-920 User Manual

CIS BH62-30024B HEAT/SINK-IC SPC-1,T1,SN COATING
CIS BH13-00012A IC-POWER SWITCH PG17/19/21,DP308O,TO-3P-5L,5P,POWER
CIS BH61-70003A SPRING CVT4857,STS304-W1/2H,T0.5,W3.8
CIS BH62-30412D HEAT/SINK A6063S,T1.8,CSH780B
CIS 0402-001215 DIODE-RECTIFIER SDS10U150S,1500V,10A,TO-220F,S
CIS 0502-001143 TR-POWER 2SC5583,NPN,150W,TOP-3L,ST,6-1
CIS BH62-00001A INSULATION-MICA MICA,W25XL35XT0.15,CSM920B
CIS BH71-10436A COVER-BRKT H/S CSM920B,SPTE,T0.5,SM,SE
CIS 6021-000118 NUT-HEXAGON 1C,M3,ZPC(YEL),SM20C
CIS BH62-30425A HEAT/SINK A1050S,T1.0,CSM920B
CN201 3711-004182 CONNECTOR-HEADER BOX,10P,1R,STRAIGHT,SN
CN203 3711-004351 CONNECTOR-HEADER NOWALL,16P,1R,2.54MM,STRAIGHT,SN
CN204 3711-004352 CONNECTOR-HEADER BOX,15P,1R,2MM,STRAIGHT,SN
CN205 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN206 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN207 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN209 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN211 3711-004349 CONNECTOR-HEADER BOX,3P,1R,2MM,STRAIGHT,SN
CN212 3711-004349 CONNECTOR-HEADER BOX,3P,1R,2MM,STRAIGHT,SN
CN401 3711-003989 CONNECTOR-HEADER NOWALL,4P,1R,8mm,STRAIGHT,SN
CN405 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN406 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN407 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN408 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN409 3711-000885 CONNECTOR-HEADER 3WALL,3P,1R,2.5mm,STRAIGHT,SN
CN410 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN411 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN412 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN413 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN601 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN602 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN603 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
CN606 BH71-40300A PIN-HINGE BRASS,D2.36,SN,HEAT/SINK
D201 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D202 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D203 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D262 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D264 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D301 0402-000272 DIODE-RECTIFIER UF4001,50V,1A,DO-41,TP
D302 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D401 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D402 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D403 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D405 0402-000274 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP
D406 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D407 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D408 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
7 Electrical Parts List
7-6 PG17**/PG19**/PG21**
Loc. No. Code No. Description Specification Remarks

Compaq MV-920 Specifications

General

Brand	Compaq
Model	MV-920
Category	Monitor
Language	English
