IC203 1103-001150 IC-EEPROM 24C081,8KBIT,DIP,8P,300MIL,10MS,5V
IC204 1103-001087 IC-EEPROM 24LC21,128x8BIT,DIP,8P,300MIL,
IC261 1204-001448 IC-DEF. PROCESSOR SAM9222G,DIP,32P,300MIL,PLASTI
IC402 1203-001099 IC-PWM CONTROLLER 3843,DIP,8P,250MIL,PLASTIC,30V
IC403 BH13-00009A IC-H/V CONVERGENCE PG17/19,AN5452,SIP,12P,H/V CONVER
IC501 1203-000610 IC-PWM CONTROLLER 494,DIP,16P,300MIL,PLASTIC,40V
IC502 1201-000420 IC-OP AMP 358,DIP,8P,300MIL,DUAL,100V/mV
IC602 0604-001018 PHOTO-COUPLER DAR-TR,63-125%,200mW,DIP-4,ST
IC604 1203-000002 IC-POSI.ADJUST REG. 431,TO-92,3P,PLASTIC,2.44/2.
IC661 0604-001018 PHOTO-COUPLER DAR-TR,63-125%,200mW,DIP-4,ST
IC662 BH13-00010A IC-POWER SWITCH S-III,TNY254P,DIP,8P,POWER SWITCH,5W
JP495 2004-001298 R-METAL 82Kohm,2%,1/4W,AA,TP,2.4x6.4mm
L260 2701-000154 INDUCTOR-AXIAL 220uH,10%,4.2x9.8mm
L401 2701-000187 INDUCTOR-AXIAL 4.7uH,10%,4.2x9.8mm
L402 BH27-20345J COIL-HORIZ.CENTER 3.5mH,OB6*30-1HHA,BULK,USTC0.08*8#
L403 BH26-00048A TRANS-H.LINEARITY 4.3UH,6P,DR 15*27.5(6.0),YL-81,4.3UH
L404 2701-000179 INDUCTOR-AXIAL 33uH,10%,4.2x9.8mm
L501 2701-000179 INDUCTOR-AXIAL 33uH,10%,4.2x9.8mm
L503 2701-000187 INDUCTOR-AXIAL 4.7uH,10%,4.2x9.8mm
L521 BH27-00018A COIL-CHOKE 6.8UH,DR08*11,BULK,+/-10%
L601 BH27-00025A COIL-LINE FILTER 24.0MH,SQE-2828,BK
LC601 2901-001161 FILTER-EMI AC LINE 250V,3A,UL/CSA/SEMKO,2200PF,36X24X40
MP1.1 BH41-00027A P.C.B-MAIN PG,FR1,247*330,1.6T
POS601 1404-000002 THERMISTOR-PTC 9ohm,20%,TR,RECT
Q261 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q262 0501-000303 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120
Q263 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q264 0505-000013 FET-SILICON VN2222LL,N,60V,150mA,7.5ohm,40
Q290 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q301 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q401 0501-000303 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120
Q404 0505-001357 FET-SILICON SKS4N20,N,200V,3A,1.3OHM,27W,TO-220
Q451 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q452 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q453 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q454 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q455 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q460 0505-001305 FET-SILICON SKS10N20,N,200V,6.9A,0.36OHM,39W
Q501 0501-000143 TR-SMALL SIGNAL 2N6520,PNP,625mW,TO-92,30-20
Q521 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q522 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q523 0501-000581 TR-SMALL SIGNAL 2N3906,PNP,625mW,TO-92,TP,100
Q553 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92,80-25
Q554 0501-000413 TR-SMALL SIGNAL KSP44,NPN,625mW,TO-92,50-200
Q630 0501-000010 TR-SMALL SIGNAL KSC1008,NPN,800mW,TO-92,TP,120
Q632 0501-000586 TR-SMALL SIGNAL KSC945,NPN,250mW,TO-92,TP,120
Q664 0501-000303 TR-SMALL SIGNAL KSA733,PNP,250mW,TO-92,TP,120
!
!
!
!
!
7 Electrical Parts List
PG17**/PG19**/PG21** 7-9
Loc. No. Code No. Description Specification Remarks
