CR11 2201-000689 C-CERAMIC,DISC 8pF,0.5pF,50V,CH,TP,4x3.5,5
CR12 2201-000504 C-CERAMIC,DISC 39pF,5%,50V,SL,TP,-,5
CR14 2305-000009 C-FILM,MPEF 100nF,5%,250V,TP,13x11x6.5,7.5
CR16 2401-003479 C-AL 0.47UF,20%,100V,WT,TP,5X11MM,5
CR17 2401-003479 C-AL 0.47UF,20%,100V,WT,TP,5X11MM,5
CR21 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
CRC 2201-002080 C-CERAMIC,DISC 0.027NF,5%,500V,NPO,TP,6.3X4MM,5
CRP 2301-000188 C-FILM,PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5
D104 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
D151 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB03 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DB04 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DB05 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB07 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG03 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DG04 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DG05 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG07 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DR03 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DR04 0401-000006 DIODE-SWITCHING BAV21,250V,250mA,DO-35,TP
DR05 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DR07 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
EY1 6042-000001 EYELET ID2.2,OD2.7,L3.1,SN,BSS3-E/EH
EY2 6042-000001 EYELET ID2.2,OD2.7,L3.1,SN,BSS3-E/EH
EY5 6042-000002 EYELET ID1.5,OD2,L3.1,SN,BSS3-E/EH
EY6 6042-000002 EYELET ID1.5,OD2,L3.1,SN,BSS3-E/EH
EY7 6042-000002 EYELET ID1.5,OD2,L3.1,SN,BSS3-E/EH
IC101 1201-001287 IC-VIDEO AMP 52748,DIP,36P,500MIL,TRIPLE,-,
IC103 1204-001547 IC-OSD PROCESSOR KS2501B-10,DIP,24P,300MIL,PLASTIC,6.5V
L101 2701-000125 INDUCTOR-AXIAL 150uH,10%,2.8x7mm
L102 2701-000125 INDUCTOR-AXIAL 150uH,10%,2.8x7mm
LB03 2701-001069 INDUCTOR-AXIAL 180NH,10%,3X7MM
LG03 2701-001069 INDUCTOR-AXIAL 180NH,10%,3X7MM
LR03 2701-001065 INDUCTOR-AXIAL 0.22UH,10%,3X7MM
MP1.1 BH41-00028A PCB-VIDEO FR1,247*330,1.6T
Q101 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q102 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q104 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
Q141 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,TP,100
QB02 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92,80-25
QB03 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,TP,60-2
QB51 0501-000581 TR-SMALL SIGNAL 2N3906,PNP,625mW,TO-92,TP,100
QG02 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92,80-25
QG03 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,TP,60-2
QG51 0501-000581 TR-SMALL SIGNAL 2N3906,PNP,625mW,TO-92,TP,100
QR02 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92,80-25
QR03 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,TP,60-2
7 Electrical Parts List
7-18 PG17**/PG19**/PG21**
Loc. No. Code No. Description Specification Remarks
