Compaq MV-920 User Manual

BD150 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
BD151 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500,2375G
C151 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C152 2201-000573 C-CERAMIC,DISC 47pF,5%,50V,CH,TP,6.5x3.0,5
C153 2201-000573 C-CERAMIC,DISC 47pF,5%,50V,CH,TP,6.5x3.0,5
C154 2201-000573 C-CERAMIC,DISC 47pF,5%,50V,CH,TP,6.5x3.0,5
C155 2201-000573 C-CERAMIC,DISC 47pF,5%,50V,CH,TP,6.5x3.0,5
C161 2201-000119 C-CERAMIC,DISC 100nF,+80-20%,50V,Y5V,TP,8x3.5
C162 2401-001509 C-AL 47uF,20%,16V,GP,TP,6.3x7mm,2.5
C166 2301-000188 C-FILM,PEF 1nF,5%,100V,TP,10.5x12.5x6.5,5
C801 2401-001509 C-AL 47uF,20%,16V,GP,TP,6.3x7mm,2.5
C802 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
C803 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,2.3X3
CB51 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
CB52 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
CG51 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
CG52 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
CG61 2401-000597 C-AL 1uF,20%,50V,GP,TP,4x7mm,1.5mm
CIS BH39-00094A CBF-HARNESS 6P/7P,150MM,RED/GRN/BLU,UL1354
CIS BH70-00019A SHIELD-BNC(COVER) PG17HS,SECC,T0.5
CIS BH71-00020A SHIELD-BNC(REAR) PG17HS,SPTE,T0.2
CIS BH75-00061A UNIT/SHIELD-VIDEO PG17HS,A1050S
CIS 0205-001027 OIL-SILICON G746
CIS BH61-00002A SPRING-VIDEO CDB7907,STS H14 ,T1.0,NORMAL CDT
CIS BH62-00018A HEAT SINK-VIDEO A6063S,T2.0,-,PG17NO
CIS BH71-00022A SHIELD-VIDEO PG17HS,A1050S,T1.0
CIS BH72-00058A HOLDER-VIDEO PG17HS,ABS+PC,5V(NONE,1,PHOSPHATE)
CIS BH73-00001B HOLDER-RUBBER CDB7907,SILICON V2,GRAY,4,15L,17
CIS BH75-00069A UNIT/BRKT PG17HS,DB-1529B
CIS 0203-001199 TAPE-KRAFT #53110,T0.1,W6,L2000M,BRN
CIS 0203-001200 TAPE-PAPER #53128,T0.15,W5.5,L2000M,BEIGE
CIS BH39-10307X CBF-POWER/CORD DET,H05VV-F,250V/6A,IVY,1830MM
CN101 3711-004350 CONNECTOR-HEADER BOX,7P,1R,2MM,ANGLE,SN
CN102 3710-001523 CONNECTOR-SOCKET 16P,1R,2.54MM,ANGLE,AUF
CR51 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
CR52 2401-000443 C-AL 10uF,20%,25V,GP,TP,5x5mm,2mm
D151 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB01 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB02 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB53 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DB54 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG51 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG52 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG53 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DG54 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DR51 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
DR52 0401-000005 DIODE-SWITCHING 1N4148,100V,200MA,DO-35,TP
7 Electrical Parts List
PG17**/PG19**/PG21** 7-21
Loc. No. Code No. Description Specification Remarks
7-3 SOG PCB Parts

Compaq MV-920 Specifications

General

Brand	Compaq
Model	MV-920
Category	Monitor
Language	English
