QUICKSPECS
2 DA-10709-01-001 — 10.23.2000
Compaq
710 CR
Monitor
SPECIFICATIONS (continued)
Compaq P710 CRT Monitor (continued)
Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent
Manageability.
User Controls
Sizing and Positioning Yes
Pincushion Yes
Pincushion Balance Yes
Trapezoid Yes
Tilt (rotation) Yes
Color temperature Yes
Degauss Yes
Parallelogram Yes
Individual color control No
Zoom No
Moiré Cancellation Yes
Convergence No
Factory Reset Yes
Corner Purity Adjustment No
AssetControl Yes
Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.
Pixel Clock Frequency (Maximum) 208 MHz (1600 x 1200, 76 Hz, 95 kHz)
Input Impedance 75 ohms
Horizontal Frequency 30 to 96 kHz
Vertical Frequency 50 to 130 Hz
Power Supply 90 to 260 VAC (200t o 260 VAC for Europe)
Maximum Power Rating 95 W
USB Capabilities No
Synchronized Input Separate H, V synchronized
Signal Cable Detachable 15-in D-sub to 15-pin D-sub cable. D-sub connector on
monitor
Maximum Phosphorus Size 12.8 x 9.6 in/325.1 x 243.8 mm (16 in/406.4 mm diagonal)
Dimensions (HxWxD) 16.2 x 16.1 x 17.1 in/412.6 x 410.2 x 435.3 mm
Weight 38.6 lbs/17.5 kg
Temperature
Operating 50° to 95°F/10° to 35°C
Non-operating –4° to 140°F/–20° to 60°C
Humidity
Operating 20% to 80%
Non-operating 10% to 90%
Warranty Three-year parts, three-year on-site labor, or next business day direct
replacement
Note: Certain restrictions apply. Consult the Compaq Customer Service Support Center for details.
