Tip : Clip on the ball link on the tail
control arm. Look which part of the tail
control rod slides in the guide of the tail
boom clamp to get the correct position for
the heat shrink. Clip it off again and pull
the tail control rod as far as possible to the
rear. Slide the heat shrink over the tail
control rod and shrink it carefully with a
lighter.
2
5
7
Use medium threadlock on all
screws going into metal parts
The boom support collar (7)
has one beveled side. This
must face outside. Be careful
when fixing the tail boom
braces and arrange the
collars to them.
Beveled Side
1
3
0
m
m
Heat Shrink Plastic
To Next Page
