Compass 7hv - Tail Servo Installation

Use AB Glue
0
10
20
30
40
2
Landing Gear
A
B
Tip: Do not over tighten the four 3 x 5mm
set screws as it can damage the landing
struts.
A
B
1
1
2
3
4
Pos Description Qty
1 M3x20 Socket Head Bolt 8
2 3mm Washer 8
3 3x5mm Set Screw 4
4SkidCaps 4
Tail Servo
Installation
6
7
Tip: Do not over tighten the four servo
screws as it may damage the plastic parts.
Use medium threadlock on all
screws going into metal parts
8
9
