4 16 Ethernet
Ports
16 10/100 Mbps auto-negotiating Ethernet ports
5 DC Jack Connect to external power adapter supplied in the
PS2216 kit
6 Reset button This button is used to reset the switch to factory
default.
4. Installation of Compex PS2216
This switch can be installed on a flat surface (desktop) or mounted on a wall.
Follow the steps below for proper installation.
Desktop installation
1. Unpack the switch.
2. Choose a location that is near to the electrical outlet. It is preferable to
place the switch on a desktop with a clean and sturdy surface.
3. Ensure that there is enough clearance around the unit to allow attachment
of network cables and power adapter. Connect one of the LAN ports to a
PC with an RJ45 Ethernet cable.
4. Connect the power adapter to the switch. The Power LED and the
respective PORT LED should light up.
Wall installation
1. Measure the distance between the mounting holes at the bottom of the
switch and mark the wall to match the location of the mounting holes on
the switch.
2. Drill pilot holes at the two marked locations.
3. Fix two 5/16-inch diameters flat-head mounting screws into the wall, with
the heads of the screws protruding 1/8 inch out from the wall.
4. Carefully set the switch over the screws in the wall; then slide the switch
down onto the screws, pressing it slightly to the wall.
5. Connect the power adapter to the switch. The Power LED and PORT
LED for the connected port should light up.
Using the reset button on the switch
1. Power the switch off.
2. Press and hold the reset button down.
3. Power the switch on.
4. Release the reset button. The switch will reset to factory default.
5. Specifications
Industrial
Standards
Complies with IEEE 802.3 10Base-T, IEEE 802.3u
100Base-TX and ANSI/IEEE 802.3 N-Way auto-
negotiation standards; FCC Class A; CE mark.
Interface Each unit has 16 10/100Mbps Ethernet ports (RJ-45).
Port Speed Auto-negotiation
Link Distance 100Base-TX: can support up to 100M of ‘Category 5’
Ethernet cable to PC, hub or another switch.
10Base-T: can support up to 100M of ‘Category 3, 4,
and 5’ Ethernet cable to PC, hub or another switch.
LED Indicators LED indicators are provided for status monitoring.
These include LEDs for system power, traffic activity
and link.
Dynamic memory
sharing In/Out
buffer
1.25Mbit
Forwarding Method Store-and-Forward
Number of MAC
Addresses
8K MAC Addresses
Dynamic Addresses
Learning / Filtering
Yes
Environment
Requirements
Operating Temperature::
Storage Temperature::
Operating Humidity:
Storage Humidity::
(non-condensing)
0°C to 40°C
-5°C to 60°C
10% RH to 90% RH
5% to 80% RH
Physical
Dimensions
151 x 92x 35mm (L x W x H)
Weight About 0.26 kg
Safety UL, CSA, TUV/GS
This document may become superseded, in which case you may find its latest
version at:
http://www.compex.com.sg
Disclaimer: Compex, Inc. provides this guide without warranty of any kind, either
expressed or implied, including but not limited to the implied warranties of merchantability
and fitness for a particular purpose. Compex, Inc. may make improvements and/or changes
to the product and/or specifications of the product described in this guide, without prior
notice. Compex, Inc will not be liable for any technical inaccuracies or typographical errors
found in this guide. Changes are periodically made to the information contained herein and
will be incorporated into later versions of the guide. The information contained is subject to
change without prior notice.
Trademark Information: Compex
®
, ReadyLINK
®
and MicroHub
®
are registered
trademarks of Compex, Inc. Microsoft Windows and the Windows logo are the
trademarks of Microsoft Corp. NetWare is the registered trademark of Novell Inc. All
other brand and product names are trademarks or registered trademarks of their respective
owners.
Notice: Copyright
©
2005 by Compex, Inc. All rights reserved. Reproduction, adaptation, or
translation without prior permission of Compex, Inc. is prohibited, except as allowed under
the copyright laws.
Manual Revision by Wenguang
Manual Number: M-0348-V1.7C Version 1.7, July 2006
FCC NOTICE: This device has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
device generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this device does cause harmful interference to radio or television
reception, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving
antenna.
Connect the computer into an outlet on
a circuit different from that to which
the receiver is connected.
Increase the separation between the
computer and receiver.
Consult the dealer or an experienced
radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this
device could void the user's authority to operate the equipment.
FCC Compliance Statement: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1)
(2)
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may
cause undesired operation.
ICES 003 Statement
This Class A digital apparatus complies with Canadian ICES-003
DECLARATION OF CONFORMITY: Compex, Inc. declares that the product:
Product Name: Compex 16-Port 10/100 Mbps Fast Ethernet Desktop Switch
Model No.: PS2216 conforms to the following Product Standards:
Radiated and Conducted Emission Standards:
EN55022, FCC Part 15B Class A
Immunity Standards:
EN55024
Safety Conformance:
EN61000-3-2, EN61000-3-3.
Therefore, this product is in conformity with the following regional standards: FCC
Class A ⎯ following the provisions of FCC Part 15 directive; CE Mark ⎯ following the
provisions of the EC directive.
Manufacturer’s Name: Compex Systems Pte Ltd
Address: 135 Joo Seng Road, PM Industrial Building, #08-01, Singapore 368363
Warranty Registration Card
Register via the Internet at http://www.cpx.com or
http://www.compex.com.sg
[M-0088-V2.4C]
To activate the warranty, please complete this card and return to Compex within
ninety (90) days from the date of purchase.
Please e-mail this warranty card to support@compex.com.sg.
Product: Purchase Date: Model: Serial No:
Name: E-mail:
Company:
Address:
Postal/Zip Code: Country:
Phone: ( )
Note:
For purchases within U.S.A and Canada, please fax to Compex, Inc. at
(714) 482 0332
For purchases outside U.S.A and Canada, please fax to Compex Systems Pte
Ltd at (65) 6280-9947
