INSTALLATION INSTRUCTIONS
Telescope
Use4-40x3/4”MachineScrewsand4-40NylocNuts
toattachonesideoftheplasticringtotheBracket
withweldedwasher.
PlacetheBaseoftheTelescopeunderthelipofthe
plasticringandattachtheotherhalfoftheplasticring.
PlasticRing
Halves
Bracketwithweldedwasher
(Push1-3/8”Plugsintobothends)
TelescopeBase
AssembleTelescopeasshownabove.
ThenattachtheBrackettotheBarrier
withPanelClamps,3/8”x2”Carriage
BoltsandHexNuts.
©2003 Swings & Things Inc.
Using a small phillips head screw driver
and a 1/4” socket.
