Component Playgrounds PH45 - Steering Wheel and Telescope Assembly

26 pages

To Next Page

To Previous Page

INSTALLATION INSTRUCTIONS

Steering Wheel

Pivot

Plug

Plastic

Pivot

7/16”

Washer

Bracketwithwelded

bolt.Pushtwo1-3/8”

Plugsintheends

3/8”

Nyloc

Nut

Assemble Steering Wheel as

shownabove.

ThenattachBrackettothe

Barrierwithpanelclamps

and3/8”x2”CarriageBolts

andHexNuts.
