19COMPRAG Screw air compressor A-Series
Model
Compressor dimensions Packaging dimensions
Length
L, mm
Width D,
mm
Height H,
mm
Weight ,
kg
Length
L, mm
Width D,
mm
Height H,
mm
Weight,
kg
AR07.. / ARD07..
1510 700
1490
447 1610 800 1660
1540
AR11../ ARD11..
1653
457
1600 800 1830 1705
AR15../ ARD15.. 464
AR18../ ARD18..
1850 800 1870
631
2010 900 2070 1940
AR22../ ARD22.. 651
H
L
D
Fig. 3.4 Dimension drawing AR07..-AR22, ARD07..-ARD22
