18 Version 1.4
Model
Compressor dimensions Packaging dimensions
Length
L, mm
Width
D, mm
Height
H, mm
Weight ,
kg
Length
L, mm
Width
D, mm
Height
H, mm
Weight ,
kg
FR05-270
1500
724 1472
400
1700 825 1630
445
FRD05-270 1546 435 480
FR05-500 1855
724 1586
445
2050 880 1780
498
FRD05-500 1855 480 538
FR07-270 1500
724 1472
422
1700 825 1630
467
FRD07-270 1546 457 502
FR07-500 1855
724 1586
467
2050 880 1780
520
FRD07-500 1855 495 553
FR11-270 1500
800 1631
435
1700 900 1800
482
FRD11-270 1558 482 532
FR11-500 1855
800 1740
525
2050 950 1930
578
FRD11-500 1855 557 605
FR15-270 1500
800 1631
455
1700 900 1800
502
FRD15-270 1558 492 542
FR15-500 1855
800 1740
535
2050 950 1930
588
FRD15-500 1855 577 625
FR18-500 1855
884 1740
580
2050 1000 1930
630
FRD18-500 1905 645 695
FR-22-500 1855
884 1740
600
2050 1000 1930
650
FRD-22-500 1905 665 715
H
L
D
Fig. 3.2.2. Dimension drawing FR05..-FR22, FRD05..-FRD22
