17COMPRAG Screw air compressor F-Series
Fig. 3.1.2 Lifting and carrying FR05..-FR22, FRD05..-FRD22
Model A, mm B, mm C, mm D, mm G, mm
FR05.. / FRD05.
100
383 185
92
900
FR07.. / FRD07..
FR11../ FRD11..
130 202
FR15../ FRD15..
FR18../ FRD18..
135 302 1000
FR22../ FRD22..
3.2 Dimensions
G
AC
D
L
H
Fig. 3.2.1. Dimension drawing F05.. – F22..
Model
Compressor dimensions
Length
L, mm
Width
D, mm
Height H,
mm
Weight ,
kg
F05
973 724 964
280
F07 302
F11
1003 800 1123
315
F15 335
F18
1083 884 1123
425
F22 445
Packaging dimensions
F05
1075 825 1115
310
F07 332
F11
1100 900 1250
347
F15 367
F18
1200 1000 1250
470
F22 490
