Page 5
Note
Before placing the bottom cover,
make sure the U-shaped Boss is
at the side of the M.2 connectors
Screw the 4x Phillips enclosure
screw half way, enough to hold
the bottom cover in-place but not
too tight
Complete by tightening the
Phillips enclosure screws all the
way down, while holding the side
panels
Bring both side panels in place,
and hold them
