Building Cables for DeviceMaster Products [Documentation number: 2000430 Rev B] 19

Building Cables for DeviceMaster

Products

Overview

This chapter describes the cables and pinouts for DeviceMaster products and

covers the following topics:

• DB9 Serial Cables and Loopback Plugs

• RJ45 Serial Cables and Loopback Plugs

DB9 Serial Cables and Loopback Plugs

This section describe how to build your own null-modem or straight-through DB9

serial cables and loopback plugs.

The following DeviceMaster models support DB9 connectors:

• DeviceMaster AIR

• DeviceMaster PRO

• DeviceMaster RTS

• DeviceMaster Serial Hub (RS-232 only)

• DeviceMaster UP

Requirements Refer to the manufacturer’s installation document if you need help with connector

pinouts or cables for the peripheral device.
