DEEP LEARNING PLUS QUICK START GUIDE4
BASIC CONNECTION OVERVIEW
DL PLUS DECODING PERFORMANCE
The DL PLUS product supports the following decoding performance from video sources:
Max. Frame Rate @ Video Source Resolution
Model 2-megapixel 4/5-megapixel 8-megapixel
DL PLUS-4 4CH@100FPS 4CH@48FPS 4CH@24FPS
DL PLUS-8 8CH@200FPS 8CH@96FPS 8CH@48FPS
DL PLUS-16 16CH@400FPS 16CH@192FPS 16CH@96FPS
It is important that all channels used as video sources for DL PLUS meet this decoding specification
in order to prevent issues with product stability. If necessary, reduce resolution and/or frame rate for
video sources from their respective stream/record setup menus to ensure total decoding performance is
maintained.
For example, the following mixed load-out would be acceptable for DL PLUS-4:
Channel Resolution Frame Rate
Channel 1 1920x1080 25FPS
Channel 2 2592x1520 12FPS
Channel 3 2592x1520 12FPS
Channel 4 3840x2160 6FPS
