3
PM5 Views
USB cable (optional)
to computer or
phone/tablet
Race system jacks (2)
Reset button
USB flash drive port
Battery cover
Bottom View of PM5
Back View of PM5
Sensor cable
to flywheel
PM5 Menu Map (Visit concept2.com/PM5 for more information.)
Total elapsed time.
More Information
Cleaning the PM
Use a cloth lightly dampened with water
only. Do not spray with a cleaner or leave
in the rain.
Troubleshooting
Visit concept2.com/pm5.
Using a Heart Rate Monitor:
Memory
Strokes per minute (s/m).
Pace (in time) per 500m (calculated each stroke).
Your pace is the amount of time it takes to row
or ski 500m. A smaller time is faster.
Total meters rowed or skied.
Heart rate
(Optional. Requires additional chest belt.)
Average pace (in time) per
500m. This is the average
for your entire workout.
Projected meters in 30 minutes if the current
average pace is maintained.
Split meters. The number
of meters rowed or skied in
a given distance or time. In
Just Row / Just Ski splits are
ve minutes long.
UNITS
Push at any time to change units between Meters
(m), Pace (time/500m), Watts and Calories (cal).
DISPLAY
Push at any time to change display between All Data, Force
Curve, Paceboat/Pace Skier, Bar Chart, and Large Print.
Sample Display
Remove D Cell (LR20)
batteries from the PM5
if monitor will not be
used for a period of four
months or more.
D
D
The PM5 will receive and display heart
rate data directly from a Bluetooth Smart,
Suunto™, Garmin
®
or ANT+
™
HR chest belt.
See More Options for set up.
WARNING! Heart rate monitoring systems may be inaccurate. Over-exercising
may result in serious injury or death. If you feel faint, stop exercising immediately.
USB-B
MENU
Push to power up the PM, display the
previous menu or save workout results.
