Assembly Instructions
Tubes Table
2. Connect table top support rails to table support frames along flat tube, with bent side facing down, with
M8x50 CSK bolt (C). Ensure that table top support rails mould around the tubing. Connect both table top
support rails to the one table support frame initially and then attached the second table support frame
afterwards.
3. Before attached table legs to the frame, ensure double saddle washers (E) are added in-between the
bottom of the two support frames. Loosely insert M8x50 CSK screws (C) to hold in place. Once both
double saddle washers are in place, flip frame upside down so that table support rails are on the floor.
4. Add 8 x double saddle washer (E) along edges of support frame and loosely screw in place. This will hold the
table legs in place. Face legs up to double saddle washers (E) and tighten. Now that legs are connected to the
frame, ensure that all screws are now tightened. Once complete, flip table onto feet.
2
3
4
