S
PECIFICATIONS:
Power (ultralinear operation): 55 watts per channel RMS both chan-
nels driven into 4 ohms from 30Hz to 15KHz at no more than 1% total
harmonic distortion or intermodulation distortion (can be re-connected
internally for 8 or 16 ohm loads).
Power (triode operation): 25 watts per channel RMS both channels
driven into 4 ohms from 30Hz to 15KHz at no more than 1.5% total
harmonic distortion or intermodulation distortion.
Sensitivity: 820 mv to full power.
Phase: Phase correct (non-inverting)
Frequency response: 20Hz to 20KHz +0, -.5dB
Hum and noise: 95dB below full power output.
Input impedance: 100K ohms.
Dimensions: 13.25D x 17.625W x 7H inches.
Weight: 48 lbs.
Internal Fuses
The MV60 power transformer is protected by a fuse on the ac power line
(F1, located in a compartment in the ac line-cord receptacle mounted
on the back of the amplifier), and by a separate fuse (F2, located on the
pc board) for the secondary windings for the filament supply. A failure of
either of these fuses is a symptom of a more serious problem, and a
competent service technician should be consulted. In no event should
fuses be replaced with a value or type different than that originally
supplied. The correct fuse values and types are:
F1: 5x20mm 5 amp T-type if configured for 100 or 120V:
5x20mm 3 amp T-type if configured for 220 or 240V.
F2: 3AG 4 amp, slow blow
MV60 Owner’s Manual 11
