COBRA SPECIFICATIONS
• Effective Length: (from stylus to pivot point) 239mm
• Overhang: (from Stylus to spindle Centre) 17.3mm
• Offset: (Headshell Offset in degrees) 23 Degrees
• Cartridge Fixing Centres: 12.7mm for standard M2.5
socket head cap screws
• Mounting Distance: (from pivot to spindle centre) 221.7
• Arm Mount Hole Pitch: 76mm by 4 equidistant cardinal
points for 4mm metric socket head cap screws.
NOTE: Arm mount centre is offset from arm pivot
by 60mm which allows for significant adjustment
for mounting on various turntable systems. So
whilst the 76mm hole PCD is similar to the Graham
mount the location of the holes is further away.
An optional mounting plate adaptor is available for
customised mounting requirements.
• Depth Below mounting surface: 0mm (no items
extend below the surface of standard Cobra mount).
• Radial Clearance for Counterweight: 90mm
THE
COBRA
SPECS
page 56
